OUTPUT VALUES
| Standby Power | Voltage | 230/400 |
| Standby Power | kVA | 22 |
| Standby Power | kW | 17,6 |
| Standby Power | Amper | 32 |
| Prime Power | Voltage | 230/400 |
| Prime Power | kVA | 19,8 |
| Prime Power | kW | 15,8 |
| Prime Power | Amper | 28,5 |
DIMENSIONS & WEIGHT
| Without Canopy | Width | 900 mm |
| Without Canopy | Length | 1800 mm |
| Without Canopy | High | 1100 mm |
| Without Canopy | Weight | 500 kg |
| Without Canopy | Fuel Tank Capacity | 180 lt |
| With Canopy | Width | 900 mm |
| With Canopy | Length | 2000 mm |
| With Canopy | High | 1400 mm |
| With Canopy | Weight | 650 kg |
| With Canopy | Fuel Tank Capacity | 180 lt |
ALTERNATOR INFORMATIONS
| Standby Power (kVa/kw) | 25/20 |
| Prime Power (kVa/kw) | 23/18 |
| Brand | TRIO |
| Output Voltage (V) | 231/400 |
| Frequency (Hz) | 50 |
| Stationary Vol. Regulation(±) | 0,01 |
| Short Circuit Current | %300 (10 sec) |
| Insulation | H |
| Protection | IP23 |
| E ciency (%) | 88 |
| Overloading | 110% for 1 hour |
| Power Factor (cos Q=0.8) | 0,8 |
| Tot. Harmonic Dist. Rate | <1 % |
| Connection Type | Star |
| Number of Pole | 4 |
| Number of Bearing | Single |
DIESEL ENGINE
| Brand | Ricardo |
| Model | 4100 D |
| Max. Total Output Pow. (kWm/hp) | 30/40 |
| Cylinder Displacement (lt) | 2,043 |
| Cylinder Orientation | 4 Single Line |
| Bore x Stroke(mm*mm) | 85*95 |
| Compression Ratio | 18;1 |
| Governor Type | Mechanic |
| Rotation | 1500 RPM |
| Aspiration System | Natural |
| Injection | Direct |
| Cooling System | Water Cooled |
| Electrical System(V DC) | 12 |
| Oil Capacity (lt) | 8 |
| Engine Coolant Capacity (lt) | 14 |
| Fuel Cons. %50 (lt/h) | 2,41 |
| Fuel Cons. %75 (lt/h) | 3,9 |
| Fuel Cons. %100 (lt/h) | 5,28 |
